This grain chiller reaches deep into the grain pile. The center of a grain pile gets hot first. If you do not cool it, the grain spoils from the inside out. This product sends cold air deep down. It removes heat from the center. Your grain stays cool all the way through. Our company has 17 years of experience. Our factory is 7000 square meters with 52 workers. We follow ISO9001. We do 100% full inspection during production. Finished products are checked by sample. No minimum order quantity. We accept third party inspection. We have a weekly delivery meeting to ensure on time shipping. For foreign orders, we provide free spare parts. For batch problems, our company takes responsibility.
Three Powerful Models with Full Specifications
| Parameter | FKCGL-550E2 | FKCGL-850E2 | FKCGL-1050E2 |
| Rated cooling capacity | 55 kW | 85 kW | 105 kW |
| Rated airflow | 3580 m³/h | 5000 m³/h | 6200 m³/h |
| Max airflow | 14000 m³/h | 20000 m³/h | 27000 m³/h |
| Refrigerant (optional) | R22 / R407C | R22 / R407C | R22 / R407C |
| Refrigerant charge | 30 kg | 45 kg | 60 kg |
| Power supply | 3N~380V 50Hz | 3N~380V 50Hz | 3N~380V 50Hz |
| Total power | 25.5 kW | 38.5 kW | 55.8 kW |
| Supply air temperature range | 10-30°C | 10-30°C | 10-30°C |
| Relative humidity | 60%-75% | 60%-75% | 60%-75% |
| Supply air static pressure | 2500 Pa | 3600 Pa | 4300 Pa |
| Running current | 51.3 A | 78.2 A | 117.6 A |
| Wire size (mm²) | 16 | 25 | 35 |
| Outlet diameter | DN500 mm | DN550 mm | DN600 mm |
| Unit dimension (mm) | 2900×1900×2450 | 3600×1900×2450 | 4300×1900×2450 |
| Net weight | 1600 kg | 2300 kg | 3100 kg |
This grain chiller has PLC intelligent full automatic control. The fan is variable frequency. You can adjust the fan speed to save power. The unit also comes with wheels and handles. You can move it around the warehouse easily. The air outlet is large (DN500 to DN600). That allows high airflow without too much resistance.
Use this product for very large grain depots, port silos, and rice mills. It reduces grain loss significantly. One machine can serve a whole warehouse. We support OEM and ODM for this grain chiller. You can customize the color, control system, or refrigerant type. Custom development takes about one month. Samples are not free. Standard delivery is 30-35 days for custom orders. Payment for custom orders is 50% deposit and 50% before shipment. For standard orders, payment is 30% deposit and 70% before shipment. We accept USD, EUR, and RMB. We help with CE or other certificates. You pay the fee, we do the work. Choose this product for deep grain cooling. Your customers will see less spoilage and better grain quality.
