Large Scale Commercial Heater

Large Scale Commercial Heater

This large scale commercial heater is a professional hot water solution for commercial applications. Hangzhou Honny Heat Energy Technology Co., Ltd. was established in 2009 and has extensive experience in the heat pump industry. Our factory covers 7,000 square meters and employs 52 skilled workers. This large scale commercial heater is designed for distributors and agents worldwide and is suitable for a wide range of commercial applications.
High Performance for Large Commercial Projects

This large scale commercial heater is a professional hot water solution for commercial applications. Hangzhou Honny Heat Energy Technology Co., Ltd. was established in 2009 and has extensive experience in the heat pump industry. Our factory covers 7,000 square meters and employs 52 skilled workers. This large scale commercial heater is designed for distributors and agents worldwide and is suitable for a wide range of commercial applications.

Complete Specifications for Four Models

We offer four standard models: KFRS-18E2, KFRS-22E2, KFRS-36E2, and KFRS-72E2.
We also offer a high-temperature version capable of providing outlet water temperatures of up to 75°C. Standard high-temperature models include the KFRS-20K7 and KFRS-45K7. These units use R134a refrigerant and scroll compressors, with optional variable-frequency water pumps and variable-frequency fans.

Agent Support and Quality Assurance

Our factory operates under the ISO 9001 quality management system. Every unit undergoes a complete inspection before shipment, and key components are subject to additional quality checks. Third-party inspections are also accepted upon request.
This large scale commercial heater uses R410A refrigerant and operates reliably in ambient temperatures ranging from -15°C to 43°C. Installation is simple with standard DN25 or DN40 pipe connections. Models KFRS-18E2, KFRS-22E2, and KFRS-36E2 are available with optional built-in water pumps. All models support auxiliary electric heating and indoor signal control. Models KFRS-36E2 and KFRS-72E2 also support modular control.
For overseas distributors and agents, we provide free spare parts with bulk orders. In the event of verified batch-quality issues, our company will take responsibility and provide appropriate corrective support. Standard production lead time is 15–20 days.
OEM and ODM services are also available.
Choose this large scale commercial heater for hotels, factories, schools, hospitals, and large commercial buildings requiring reliable hot water solutions.


Key Specifications
ParameterKFRS-18E2KFRS-22E2KFRS-36E2KFRS-72E2
Heating capacity18 kW22 kW36 kW72 kW
Rated input power4.2 kW5.3 kW8.6 kW16.8 kW
COP4.294.154.194.17
Rated hot water output386 L/h473 L/h770 L/h1550 L/h
Hot water temp range20-55°C20-55°C20-55°C20-55°C
Floor heating capacity14 kW17.5 kW28 kW58 kW
Floor heating COP3.93.83.83.8
Circulating water flow3.1 m³/h3.8 m³/h6.2 m³/h7.8 m³/h
Water resistance≤35 kPa≤35 kPa≤50 kPa≤50 kPa
Compressor typeRotaryRotaryRotaryScroll
Number of compressors1112
RefrigerantR410AR410AR410AR410A
Noise58 dB58 dB64 dB64 dB
Net weight120 kg125 kg250 kg270 kg
Unit dimension (mm)1000×390×13701000×390×1370950×1110×16702025×1030×1995
Water pipe connectionDN25DN25DN40DN40
Ambient temperature-15~43°C-15~43°C-15~43°C-15~43°C
Water flow switchOptionalOptionalBuilt-inBuilt-in
Built-in water pumpOptionalOptionalOptionalNot built-in
Auxiliary electric heatingSupportedSupportedSupportedSupported
Indoor signal controlSupportedSupportedSupportedSupported
Modular controlNot supportedNot supportedSupportedSupported
